X431 CR3001 Full OBD2 Scanner OBD 2 Engine Code Reader Creader 3001 Car Diagnostic Tool


Free Shipping

Overview and Specifications:

Product Attribute
Item Type : Other
Hardware Version : n/a
Software Version : n/a
Model Name : tpwe
Power : n/a
Special Features : Other
Voltage : 9-18(V)
External Testing Certification : None
Item Length : 7
Item Width : 3
Item Height : 2
Item Weight : 0.252kg
Material Type : plastic
Electronic : No
Origin : CN(Origin)
Country : United States & Canada
Certification : None

LAUNCH X431 CR3001 Full OBD2 Scanner OBD 2 Engine Code Reader Creader 3001 Car Diagnostic Tool

Product Introduction:
CReader 3001 provides full OBDII/EOBD diagnostic functions and meets protocols such as ISO9141-2, ISO14230-4, SAEJ1850, and ISO15765-4.
Support Full OBD2 functions, Engine Check including:
Reading Codes: Show the detailed description of the Diagnostic Trouble Code (DTCs)
Erasing Codes & Reset: Turns off Check Engine Light (MIL), clears codes and resets monitors.
Data Stream: Reads and displays live ECU/PCM data stream, plotting functions graphically and stores freeze frame data.
I/M Readiness Status: Shows whether the various emissions-related systems on the vehicle are operating properly and are ready for inspection and maintenance testing.
Read Live Data Stream: Show the information of continuous data stream from a vehicle in live graphic (waveform) display.
View Freeze Frame Data: Check the certain vehicle conditions which are recorded by the on-board computer at the time the emission-related fault occurs.
O2 Sensor Test: Allows retrieval and viewing of O2 sensor monitor test results for the most recently performed tests from the vehicle’s on-board computer.
On-Board Monitor Test: Retrieves and displays test results for emission-related powertrain components and systems.
Read Vehicle Information: Display the information such as VIN (Vehicle Identification Number), CID (Calibration ID) and CVN (Calibration verification number), etc.
Component Test: Certain vehicle components can be actuated by commands sent from the
scanner to test their operability

Color: Black
Voltage: 9-18(V)
working temperature: 0-50(°C)

product Size: 7 * 3 * 2Cm
Packing Size: 10 * 5 * 3cm
net weight: 252G

Gross Weight: 300G
